DVS FATBOX SPARK4-RTX3080

The DVS FATBOX SPARK4-RTX3080 is a fantastic mid-range performance medium form-factor system. The dedicated RTX3080 graphics card delivers excellent graphical performance and the intel-based processors options allow up to 8 cores and 16 threads for demanding single and multi-threaded workloads. The PCIe 4.0 NVMe M.2 slot allows for blistering fast storage options. There is also a PCIe 3.0 NVMe M.2 slot available for a secondary NVMe drive. The three 2.5” drive bays allow for higher capacity storage and RAID options. The FATBOX SPARK4-RTX3080 is excellent for local 3D interactives and demanding digital signage applications.


Specifications

  • DVS FATBOX Chassis - 247 x 211 x 366mm (WxDxH mm)
  • 850 Watt PSU – 100 – 240V~, 12 - 6A, 50 – 60Hz
  • Mini ITX Motherboard ( Intel Z590 Chipset )
  • Intel Processor ( 4, 6 or 8 core with Hyperthreading )
  • 8 / 16 / 32GB DDR4 Dual Channel Memory
  • nVidia RTX 3080 Graphics Card ( Up to 4 concurrent displays )
  • 2 x NVMe M.2 Storage ( Up to 2TB )
  • 2 x 2.5” SATA Storage ( Supports RAID 0 and RAID 1 )
  • 1 x 1 Gigabit Network Port
  • 1 x 2.5 Gigabit Network Port
  • Intel® 802.11ax WiFi Module + Bluetooth 5
  • Operating System - Windows Enterprise IoT LTSC 2019 or Windows 10 Pro


Variant Model Numbers

Model SSD RAID ( RAID 0, 1 )
FATBOX SPARK4-RTX3080
FATBOX SPARK4-RS-RTX3080

Graphics Card

Chipset GeForce RTX3080
Microarchitecture Turing
Memory 10GB GDDR6X
Memory Bus 320 Bit
Interface PCIe 4.0 (x16)
Microsoft DirectX Support 12 API
HDCP Ready Yes
Maximum Concurrent Displays 4 Displays
Maximum Digital Resolution 7680x4320 @ 60Hz (8K UHD)
Outputs 3 x DisplayPort 1.4, 1 x HDMI 2.1
EDID Management No
Sync Module Supported No



Downloads

  • DVS FATBOX SPARK4-RTX3080 Technical Specification
    Updated: 23-06-2021 Size: 263.82k
    DVS FATBOX SPARK4-RTX3080 Technical Specification Also covers: DVS FATBOX SPARK4-RS-RTX3080
