DVS FATBOX SPARK4-A6000 Pro
The DVS FATBOX SPARK4-A6000 Pro is a fantastic mid-range performance medium form-factor system. The dedicated A6000 graphics card delivers excellent graphical performance and the intel-based processors options allow up to 8 cores and 16 threads for demanding single and multi-threaded workloads. The professional level graphics card gives great performance as well as additional features such as EDID emulation, supplying an extra level of reliability and in the Pro+ version ( sync module ) the server can frame lock between multiple units, or Genlock to an external source. The PCIe 4.0 NVMe M.2 slot allows for blistering fast storage options. There is also a PCIe 3.0 NVMe M.2 slot available for a secondary NVMe drive. The three 2.5” drive bays allow for higher capacity storage and RAID options. The FATBOX SPARK4-A6000 Pro is excellent for local 3D interactives and demanding digital signage applications.
Specifications
- DVS FATBOX Chassis - 247 x 211 x 366mm (WxDxH mm)
- 850 Watt PSU – 100 – 240V~, 12 - 6A, 50 – 60Hz
- Mini ITX Motherboard ( Intel Z590 Chipset )
- Intel Processor ( 4, 6 or 8 core with Hyperthreading )
- 16 / 32 / 64 GB DDR4 Dual Channel Memory
- nVidia A6000 Graphics Card ( Up to 4 concurrent displays )
- 2 x NVMe M.2 Storage ( Up to 2TB )
- 3 x 2.5” SATA Storage ( Supports RAID 0, 1 & 5 )
- 1 x 1 Gigabit Network Port
- 1 x 2.5 Gigabit Network Port
- Intel® 802.11ax WiFi Module + Bluetooth 5
- Operating System - Windows Enterprise IoT LTSC 2019 or Windows 10 Pro
Variant Model Numbers
| Model | SSD RAID ( RAID 0, 1 & 5 ) | Sync Module |
|---|---|---|
| FATBOX SPARK4-A6000 Pro | ||
| FATBOX SPARK4-A6000 Pro+ | ||
| FATBOX SPARK4-RS-A6000 Pro | ||
| FATBOX SPARK4-RS-A6000 Pro+ |
Graphics Card
| Chipset | RTX A6000 |
|---|---|
| Microarchitecture | Ampere |
| Memory | 48GB GDDR6 |
| Memory Bus | 384 Bit |
| Memory Bandwidth | 768 GB/s |
| Interface | PCIe 4.0 (x16) |
| Microsoft DirectX Support | 12 API |
| HDCP Ready | Yes |
| Maximum Concurrent Displays | 4 Displays |
| Maximum Digital Resolution | 7680x4320 @ 60Hz (8K UHD) |
| Outputs | 4 x DisplayPort 1.4 |
| EDID Management | Yes |
| Sync Module Supported | Yes |
| Supported API’s | DirectX 12.0, OpenGL 4.5, Shader Model 5.1, Vulkan 1.0 |
Downloads
- DVS FATBOX SPARK4-A6000 Pro Technical Specification Also covers: Pro+ and RS Variants.
DVS FATBOX SPARK4-A6000 Pro Technical Specification
Updated: 24-06-2021 Size: 319.46k
